| Marketing Description |
| To embrace remote working, businesses must deploy both a remote VPN that is quickly accessible by multilocation users, and a high-speed in-premises solution covering wired and wireless connections. The QHora-301W supports high-speed Wi-Fi 6 and 10GbE connections, while also providing an enterprise-grade SD-WAN VPN to allow multisite VPN deployment via the cloud. The QHora-301W is a solid foundation for building a next-generation network. |
| Product Features |
- Two 10GbE ports for flexible wired network deployment
With two 10GbE ports and four Gigabit ports for WAN/LAN configurations, the QHora-301W offers flexible usage scenarios for optimized network deployment.
- Better coverage and faster Wi-Fi 6 connectivity
The QHora-301W supports Wi-Fi 6 dual-band 802.11ax (2.4GHz and 5GHz) and MU-MIMO, delivering up to 3600Mb/s speeds and allowing for more concurrent Wi-Fi clients. With eight antennas and OFDMA technology, the QHora-301W provides higher-coverage Wi-Fi signals.
- Optimized hardware performance for efficient wired and wireless networking
The QHora-301W pairs an enterprise-grade Qualcomm Quad-core 2.2GHz processor with 1GB RAM, providing support for Wi-Fi 6 and faster transfer speeds.
- Built-in antennas for high-coverage Wi-Fi signals
With eight antennas, the QHora-301W provides the perfect wireless pattern view.
- Quiet and cool operations
The QHora-301W features a fanless design for near-silent operations. Even when connected to multiple devices, the QHora-301W maintains dependable performance for offices and homes.
- Accelerate large-scale VPN deployment via SD-WAN
When a business expands into remote working and distributed workforce operations, it faces the challenge of VPN deployment efficiency and connection speed. Software-defined WAN (SD-WAN) technology effectively solves these issues - without requiring expensive enterprise-grade VPN equipment. The QHora-301W uses QuWAN that automatically deploys connected WAN services and VPN sites through software-defined networking to achieve optimal network bandwidth and transmission speeds. Not only does SD-WAN improve IT deployment and management efficiency for multisite expansion, but it also provides reliable infrastructure to enable digital transformation and remote working. The QHora-301W supports Wi-Fi 6 to offer faster wireless speeds for mobile and smart home devices, enabling multiple concurrent users. Remote workers can access company LAN resources via QuWAN, without complex VPN settings.
- Deploy flexible Mesh VPN topology with multiple QHora-301W
Deploying multiple QHora-301W at different sites enables not only high-speed wired and wireless networking, but also interconnected Mesh VPN topology via SD-WAN. The QHora-301W offers home Wi-Fi and VPN connection to companies.
- Intelligent WAN optimization
The QHora-301W prioritizes the stability of your Mesh VPN. QuWAN features intelligent WAN optimization to ensure transmission stability of the two 10GbE ports and four Gigabit ports.
- Deploy a global QuWAN network topology
QuWAN allows for the easy and flexible deployment of a global network topology for an enhanced multinational working experience. You can create multiple regions inside the global domain, and the configured regional hubs will automatically form a Mesh VPN via public IPs.
- Six SSIDs for VLAN settings, offering smooth and secure connections
The QHora-301W supports enterprise VAP (Virtual AP), allowing for running up to six SSID groups (three 2.4GHz and three x 5GHz). IT staff can configure VLAN settings for each SSID to provide groups of users/devices with connection stability, which is essential for high-density networks with high numbers of concurrent users.
- VESA-mount design for flexible deployment
With a modern appearance, the QHora-301W fits perfectly alongside other devices in modern digital homes and offices. The QHora-301W can be installed anywhere, from desk tops to walls, ceilings and under tables with VESA mounting, for efficient space utilization.
|
| General |
| Device Type |
Wireless router - 6-port switch (integrated) |
| Enclosure Type |
Desktop |
| Connectivity Technology |
Wireless, wired |
| Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, 10 Gigabit Ethernet, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6) |
| Frequency Band |
2.4 GHz / 5 GHz |
| Performance |
Maximum data rate (2.4 GHz): 1182 Mbps
Maximum data rate (5 GHz): 2475 Mbps |
| Network / Transport Protocol |
TCP/IP, PPTP, UDP/IP, L2TP, ICMP/IP, FTP |
| Encryption Algorithm |
WPA, WPA2, WEP, WPA3, Opportunistic Wireless Encryption (OWE) |
| Wi-Fi Rating |
AX3600 |
| Features |
NAT support, load balancing, VLAN support, ALG support, parental control, Access Point operational mode, wall mountable, WPS, WAN failover, reset button, fanless, MU-MIMO technology, band steering, Wireless Scheduler, Smart Connect, DFS, router mode, DNS filtering, SD-WAN support, QuWAN Network Management, QuWAN Identity Verification |
| Compliant Standards |
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6, VCCI, BSMI, JATE, CCC, IC, FCC, SRRC, NCC, RCM |
| Processor |
1 x Qualcomm IPQ8072A 2.2 GHz |
| RAM |
1 GB |
| Flash Memory |
4 GB |
| Expansion / Connectivity |
| Interfaces |
WAN / LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45
WAN / LAN: 2 x 10GBase-T - RJ-45
USB 3.2 Gen 1: 2 x |
| Aerial |
| Aerial |
Internal |
| Antenna Qty |
8 |
| Gain Level |
5 dBi |
| Power |
| Power Device |
External power adapter |
| Power Consumption Operational |
24 Watt |
| Miscellaneous |
| Included Accessories |
Power cord |
| Cables Included |
1 x network cable |
| Software / System Requirements |
| OS Provided |
QuRouter OS |
| Dimensions & Weight |
| Width |
25 cm |
| Depth |
18 cm |
| Height |
4.8 cm |
| Weight |
1.9 kg |
| Dimensions & Weight (Shipping) |
| Shipping Weight |
2.2 kg |
| Environmental Parameters |
| Min Operating Temperature |
0 °C |
| Max Operating Temperature |
40 °C |
| Humidity Range Operating |
5 - 95% (non-condensing) |
