PANDUIT Cat 6A 28AWG Shielded Patch Cord CM/LSZH Red 5 meter
PANDUIT Cat 6A 28AWG Shielded Patch Cord CM/LSZH Red 5 meter
 |
||
| Manufacturer | PANDUIT | |
| Manufacturer Part No | STP28X5MRD | |
| Marketing Description | |
| Category 6A/Class EA, F/UTP, small diameter patch cords are constructed of 28 AWG, shielded, twisted pair, solid copper (dual-rated CM/LSZH) cable with high performance RJ45 modular plugs. | |
| General | |
| Network Cable Type | Patch cable - CAT 6a - IEEE 802.3af/IEEE 802.3at |
| Technology | Foiled unshielded twisted pair (F/UTP) |
| Wiring Scheme | T568B |
| Jacket Material | Low Smoke Zero Halogen (LSZH) |
| American Wire Gauge (AWG) | 28 |
| Wires per Cable | 8 wires |
| Pairs per Cable | 4 pairs |
| Plated Connector | Gold |
| Features | Booted, halogen-free, snagless, solid, labelled, strain relief, phosphor bronze connectors |
| Length | 5 m |
| Colour | Red |
| Image Colour Disclaimer | The displayed product image may be a different colour |
| Connectivity | |
| Connector | RJ-45 - male |
| Connector (Second End) | RJ-45 - male |
| Miscellaneous | |
| Compliant Standards | UL 1863, IEC 60603-7, RoHS, UL 94 V-0, cULus, ISO/IEC 11801: Class Ea, ANSI/TIA-568-C.2, ANSI/TIA-1096-A, CAN/CSA C22.2 - up to 500 MHz |
| Environmental Parameters | |
| Min Operating Temperature | -10 °C |
| Max Operating Temperature | 60 °C |
STP28X5MRD
